McQuay MCK 020A User Manual

A Series (Cooling Only – R407C)
Model : MCK020A / M4LC020B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 4.940 4.702 4.489 4.276 3.870 3.590 3.454 3.401 3.359
SC 4.940 4.702 4.489 4.276 3.870 3.590 3.454 3.401 3.359
15 TC 5.139 4.907 4.701 4.494 4.067 3.772 3.630 3.574 3.53
SC 4.868 4.631 4.419 4.207 3.808 3.531 3.398 3.346 3.305
18 TC 5.681 5.468 5.277 5.087 4.604 4.270 4.108 4.046 3.996
SC 4.670 4.436 4.227 4.018 3.636 3.373 3.245 3.196 3.156
19.4 TC 5.934 5.729 5.546 5.363 4.854 4.502 4.332 4.266 4.213
SC 4.577 4.345 4.137 3.929 3.556 3.299 3.174 3.126 3.087
20 TC 6.042 5.822 5.626 5.430 4.914 4.558 4.385 4.319 4.265
SC 4.537 4.291 4.071 3.851 3.485 3.232 3.110 3.063 3.025
22 TC 6.404 6.133 5.892 5.650 5.114 4.743 4.563 4.494 4.438
SC 4.405 4.112 3.850 3.588 3.247 3.012 2.898 2.854 2.818
24 TC 6.765 6.444 6.157 5.871 5.313 4.928 4.742 4.669 4.611
SC 4.273 3.933 3.629 3.325 3.009 2.791 2.685 2.645 2.612
HIGH AMBIENT
Model : MCK025A / M4LC025B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.658 5.387 5.145 4.903 4.752 4.510 4.394 4.350 4.314
SC 5.658 5.387 5.145 4.903 4.752 4.510 4.394 4.350 4.314
15 TC 6.203 5.826 5.489 5.153 4.994 4.740 4.619 4.572 4.535
SC 5.610 5.321 5.063 4.805 4.657 4.421 4.307 4.264 4.229
18 TC 7.689 7.024 6.430 5.836 5.656 5.369 5.231 5.178 5.136
SC 5.477 5.141 4.841 4.540 4.401 4.177 4.070 4.028 3.996
19.4 TC 8.382 7.582 6.868 6.155 5.965 5.662 5.516 5.461 5.416
SC 5.415 5.057 4.737 4.417 4.281 4.063 3.959 3.919 3.887
20 TC 8.679 7.856 7.121 6.387 6.190 5.875 5.724 5.667 5.620
SC 5.388 5.016 4.683 4.350 4.216 4.002 3.899 3.860 3.828
22 TC 9.670 8.769 7.965 7.161 6.940 6.587 6.418 6.353 6.302
SC 5.300 4.879 4.504 4.128 4.001 3.798 3.700 3.663 3.633
24 TC 10.660 9.682 8.808 7.935 7.690 7.299 7.112 7.040 6.983
SC 5.211 4.743 4.324 3.906 3.786 3.593 3.501 3.466 3.437
HIGH AMBIENT
Model : MCK030A / M4LC030C
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 8.487 8.015 7.593 7.171 6.827 6.468 6.189 6.037 5.877
SC 8.487 8.015 7.593 7.171 6.827 6.468 6.189 6.037 5.877
15 TC 9.047 8.49 7.993 7.495 7.136 6.761 6.469 6.310 6.143
SC 8.036 7.632 7.272 6.912 6.581 6.235 5.965 5.819 5.665
18 TC 10.574 9.786 9.083 8.38 7.978 7.559 7.232 7.055 6.868
SC 6.805 6.59 6.398 6.206 5.908 5.598 5.356 5.225 5.086
19.4 TC 11.286 10.391 9.592 8.792 8.371 7.931 7.588 7.402 7.206
SC 6.23 6.103 5.99 5.876 5.595 5.301 5.072 4.947 4.816
20 TC 11.592 10.675 9.856 9.038 8.604 8.152 7.8 7.609 7.407
SC 5.984 5.863 5.756 5.648 5.377 5.095 4.875 4.755 4.629
22 TC 12.61 11.621 10.738 9.856 9.383 8.89 8.506 8.297 8.078
SC 5.163 5.064 4.975 4.887 4.652 4.408 4.217 4.114 4.005
24 TC 13.627 12.567 11.62 10.673 10.161 9.627 9.212 8.986 8.748
SC 4.342 4.264 4.195 4.125 3.927 3.721 3.56 3.473 3.381
HIGH AMBIENT
28
