Page #45 background image
44
Ducted Blower B/C/D/ER Series Model – Single Compressor
Rooftop Packaged Air Conditioner – Single Compressor
Model Board Handset
SB 75 – 100B/BR L208A SLM3
SB 75 – 100D L208A SLM3
SB 75 – 100ER L208A SLM3
SB 125 – 150B/BR U1SB125 SLM3
SB 125CR U1SB125 SLM3
SB 125 – 150D U1SB125 SLM3
SB 125 – 150ER U1SB125 SLM3
RT 55 – 120A/AR U1SB125 SLM3
Seven Segment Display – SLM3
Seven Segments Faulty Indication
E1 blinking Room air sensor contact loose / short
E2 blinking Indoor coil sensor contact open
E3 blinking Outdoor coil sensor contact open
E4 blinking
Compressor overload protection /
Indoor coil sensor short /
Outdoor coil sensor short
E5 blinking Gas leak
