McQuay MCW200 User Manual

10
MODEL
WATER
FLOW

W.P.D

ENTERING AIR: DB28ºC, WB21ºC
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W

0.24
5.6 2160 1580 2020 1560 1910 1520 1770 1460 1560 1400
0.33 9.7 2430 1780 2310 1730 2160 1720 2000 1690 1840 1640
0.42
14.8 2630 1930 2460 1890 2310 1840 2160 1820 1990 1790
0.51 21.6 2780 2030 2740 2000 2430 1940 2260 1890 2090 1870

0.36 4 3230 2390 3030 2330 2790 2280 2560 2240 2500 2210
0.48 9.2 3590 2640 3360 2590 3130 2560 2890 2520 2800 2470
0.6 13.2 3870 2830 3600 2770 3360 2720 3090 2680 2980 2660
0.72
18.7 4070 3000 3800 2920 3520 2890 3240 2830 3130 2770

0.42
7.3 4060 2960 3790 2890 3560 2830 3280 2790 2860 2730
0.6 13.8 4660 3300 4380 3380 4100 3340 3790 3320 3480 3260
0.78 21.6 5090 3730 4880 3690 4420 3640 4120 3600 3790 3560
0.96 31 5390 3900 5030 3880 4700 3830 4330 3790 3990 3760

0.72
18.7 6500 4730 6090 4690 5670 4640 5190 4570 4740 4410
0.9 32.7 7010 4900 6540 4840 6070 4730 5630 4670 5170 4570
1.08 38.2 7410 5180 6840 4960 6420 4890 5920 4840 5440 4830
1.26
50 7740 5370 7210 5310 6700 5220 6180 5200 5660 5110

1.14 12.5 8640 6360 8110 6260 7490 6190 6730 6060 6140 5910
1.44 18.7 9340 6530 8780 6440 8190 6390 7580 6330 6910 6310
1.74 26.2 9910 7020 9270 6940 8610 6890 8000 6800 7360 6640
2.04
34.5 10360 7240 9680 7180 9000 7120 8330 7080 7680 6910

1.2
13.6 9570 6340 8930 6880 8230 7000 7580 6820 6980 6700
1.5 20.1 10310 7280 9680 7160 8980 7120 8290 7040 7530 6930
1.8 26.5 10940 7660 10210 7530 9470 7470 8780 7460 8030 7430
2.1
33.7 11440 8010 10680 7870 9910 7790 9120 7740 8390 7710

1.56 21.5 11900 8320 11120 8220 10310 8180 9430 8080 8600 7990
1.92 32.7 12760
9410 11890 9160 11080 9040 10190 8970 9310 8570
2.28
40.7 13460 9680 12540 9610 11620 9530 10680 9400 9800 9020
2.64
54.3 14000 9940 13060 9790 12100 9680 11130 9580 10160 9340
NOTES:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN
SPEED MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
TOTAL:TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL       
MEDIUM
TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.8 0.8 0.8 0.8
LOW
TOTAL 0.66 0.6 0.65 0.65 0.68 0.7 0.71
SENSIBLE 0.58 0.55 0.58 0.6 0.62 0.63 0.66
