27
Electrical Data (50Hz)
MODEL
MOTOR
E/20
POWER SOURCE V/Ph/Hz 220~240/1/50
RATED INPUT POWER W 21 33 45 65 103 105 133
RATED RUNNING CURRENT
A 0.10 0.15 0.20 0.30 0.47 0.48 0.60
POLES 6
MOTOR
E/20
POWER SOURCE V/Ph/Hz 220~240/1/50
RATED INPUT POWER W 42 59 67 111 157 177 221
RATED RUNNING CURRENT
A 0.19 0.27 0.30 0.50 0.71 0.80 1.00
POLES 4
MOTOR
E/20
POWER SOURCE V/Ph/Hz 220~240/1/50
RATED INPUT POWER W 47 69 83 149 205 219 271
RATED RUNNING CURRENT
A 0.21 0.31 0.38 0.68 0.93 1.00 1.23
POLES 4
MOTOR
E/20
POWER SOURCE V/Ph/Hz 220~240/1/50
RATED INPUT POWER W 51 73 97 157 215 237 281
RATED RUNNING CURRENT
A 0.23 0.33 0.44 0.71 0.98 1.08 1.28
POLES 4
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL ELECTRIC DATA ARE BEING TESTED UNDER HIGH SPEED.
