McQuay MCW200

2
Nomenclature
8 R B - A A F - C200
Description of Products
A-Standard Drain Pan
F-Extended Drain Pan
G-Extended Drain Pan+2Way Valve
H-Extended Drain Pan+3Way Valve
I-Standard Drain Pan+2Way Valve
J-Standard Drain Pan+3Way Valve
K-Standard Drain Pan+ Controller
L-Extended Drain Pan+ Controller
M-Extended Drain Pan+2Way Valve+ Controller
N-Extended Drain Pan+3Way Valve+ Controller
O-Standard Drain Pan+2Way Valve+ Controller
P-Standard Drain Pan+3Way Valve+ Controller
1-100mm Extended Drain Pan
2-200mm Extended Drain Pan
Omitted for Standard Drain Pan
F
Material of Drain Pan
A-Standard Material
S-Stainless Steel
Power Supply
A-220-240V/1Ph/50Hz
F-380V/3Ph/50Hz
K-208-230V/1Ph/60Hz
N-115V/1Ph/60Hz
W-265-227V/1Ph/60Hz
With Filter
B-Back Return Air Plenum
D-Bottom Return Air Plenum
Pipe Connection
R-Facing Air Flow Right Hand
L-Facing Air Flow Left Hand
0-0Pa External Static Pressure
3-30Pa External Static Pressure
6-60Pa External Static Pressure
8-80Pa External Static Pressure
“ - ”: Original Design
“A”: First Design Improve
McQuay Ceiling Concealed Chilled Water FCU
C-3 Rows And 2 Pipes(3+0)
H-4 Rows And 4 Pipes(3+1)
F-4 Rows And 2 Pipes(4+0)
Nominal Air Flow(CFM)
(CFM,1CFM=1.7m
3
/h)
MCW
Export
E1
-
