17
MODEL
WATER
FLOW
W.P.D
ENTERING WATER TEMPERATUREºC
6 7 8 9 10
TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE TOTAL SENSIBLE
W W W W W W W W W W
0.24
0.51 1925 1408 1802 1350 1712 1257 1619 1261 1386 1166
0.33 0.96 2159 1530 1978 1436 1894 1431 1710 1439 1616 1343
0.42
1.56 2337 1668 2161 1530 1978 1523 1894 1554 1709 1465
0.51 2.29 2430 1753 2445 1620 2159 1615 1983 1607 1798 1525
0.36 2.19 2882 2134 2703 2025 2497 1891 2343 1945 2233 1847
0.48 3.89 3189 2274 2877 2154 2749 2115 2470 2142 2461 2020
0.6 6.08 3434 2444 3171 2240 2877 2258 2706 2279 2558 2172
0.72
8.76 3553 2582 3392 2370 3123 2391 2850 2415 2702 2262
0.42
3.08 3619 2629 3374 2507 3181 2350 3011 2415 2541 2280
0.6 6.29 4132 2837 3755 2810 3594 2769 3241 2825 3058 2666
0.78 10.6 4520 3209 4290 2990 3787 3015 3615 3066 3259 2909
0.96 16.1 4720 3358 4493 3140 4175 3178 3804 3224 3436 3070
0.72
10.04 5797 4213 5418 4071 5070 3842 4755 3954 4224 3683
0.9 15.69 6225 4218 5606 4021 5315 3914 4813 3969 4543 3737
1.08 22.59 6582 4452 6016 4010 5500 4047 5196 4116 4681 3959
1.26
30.75 6772 4622 6432 4300 5951 4323 5419 4421 4872 4181
1.14 5.53 7700 5665 7220 5432 6705 5120 6170 5247 5478 4942
1.44 8.83 8296 5621 7520 5354 7177 5293 6481 5387 6072 5161
1.74 12.89 8809 6046 8156 5630 7383 5702 7014 5786 6326 5434
2.04 17.72
9061 6237 8634 5810 7989 5896 7315 6017 6617 5656
1.2
6.44 8525 5654 7956 5968 7368 5794 6951 5910 6215 5602
1.5 10.1 9151 6269 8292 5949 7870 5896 7083 5996 6614 5676
1.8 14.49 9731 6588 8981 6100 8113 6182 7696 6342 6910 6080
2.1 19.72 10012
6896 9526 6370 8800 6448 8009 6584 7234 6313
1.56 11.21 10604 7414 9901 7136 9224 6765 8649 6989 7667 6675
1.92
16.98 11321 8096 10186 7610 9710 7491 8708 7623 8176 7009
2.28 23.94
11958 8330 11033 7790 9953 7889 9363 7991 8428 7383
2.64 32.1 12247
8564 11652 7930 10740 8012 9775 8148 8755 7646
NOTES:
1) THE COOLING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN
SPEED MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
TOTAL:TOTAL COOLING CAPACITY SENSIBLE:SENSIBLE COOLING CAPACITY
Cooling Capacity Correction Factors:
MODEL
MEDIUM
TOTAL 0.85 0.82 0.84 0.84 0.87 0.85 0.86
SENSIBLE 0.78 0.75 0.78 0.8 0.8 0.8 0.8
LOW
TOTAL 0.66 0.6 0.65 0.65 0.68 0.7 0.71
SENSIBLE 0.58 0.55 0.58 0.6 0.62 0.63 0.66
