20
MCW-F
MODEL
WATER
FLOW
W.P.D
ENTERING AIR: DB21ºC
ENTERING WATER TEMPERATUREºC
40 45 50 55 60 65 70 75 80
W W W W W W W W W
0.24
0.4 1701 2148 2595 3042 3478 3925 4383 4819 5267
0.33 0.8 1821 2301 2780 3260 3740 4209 4689 5168 5659
0.42 1.2
1897 2399 2890 3391 3904 4394 4896 5386 5899
0.51 1.8 1952 2464 2977 3478 4002 4514 5027 5539 6052
0.36 1.8 2252 2836 3441 4035 4629 5223 5807 6402 6986
0.48 3.1 2513 3180 3847 4515 5182 5839 6495 7173 7840
0.6 4.9 2627 3316 4014 4713 5390 6078 6787 7455 8143
0.72
7.0 2700 3409 4129 4827 5536 6256 6954 7674 8393
0.42 2.5 3266
4116 4987 5827 6697 7558 8408 9269 10129
0.6 5.0 3535 4562 5391 6324 7257 8180 9103 10036 10958
0.78 8.5 3680 4665 5630 6708 7568 8543 9517 10492 11446
0.96 12.9 3795 4790 5795 6791 7796 8792 9797 10782 11788
0.72
8.0 4770 6039 7298 8556 9815 11063 12321 13580 14839
0.9 12.6 4981 6304 7615 8926 10238 11549 12861 14183 15484
1.08 18.1 5130 6483 7837 9191 10534 11898 13231 14595 15939
1.26 24.6 5246
6631 8006 9381 10767 12142 13527 14902 16288
1.14 4.4 6768 8565 10362 12158 13955 15752 17549 19345 21153
1.44 7.1 7055 8951 10825 12699 14572 16446 18320 20205 22079
1.74 10.3 7275 9204 11144 13073 15002 16931 18871 20801 22730
2.04 14.2
7430 9403 11376 13349 15322 17295 19279 21241 23215
1.2 5.2
6768 8565 10362 12158 13955 15752 17549 19345 21153
1.5 8.1 7055 8951 10825 12699 14572 16446 18320 20205 22079
1.8 11.6 7275 9204 11144 13073 15002 16931 18871 20801 22730
2.1
15.8 7430 9403 11376 13349 15322 17295 19279 21241 23215
1.56 9.0 8808 11164 13531 16237 18275 20641 22010 25385 27752
1.92
13.6 9765 12255 14745 17235 19726 22216 24716 27217 29707
2.28 19.2
10063 12636 15208 17771 20343 22915 25478 28050 30612
2.64 25.7
10300 12934 15558 18182 20806 23440 26064 28688 31322
NOTES:
1) THE HEATING CAPACITY IS TESTED UNDER HIGH SPEED.THE CAPACITY UNDER MEDIUM AND LOW FAN
SPEED MUST MULTIPLY A CORRECTION FACTOR.
2) W.P.D:WATER PRESSURE DROP
Heating Capacity Correction Factors:
MODEL
MEDIUM 0.8 0.78 0.78 0.81 0.83 0.8 0.81
LOW 0.58 0.56 0.57 0.58 0.62 0.6 0.61
