Performance Characteristics
50Hz R22 SPECIFICATIONS
COOLING MODEL
MODEL : MDB075B vs. MMC075B (cooling capacity)
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
20.452 19.432 18.521 17.610 16.700 15.607
13.9
SC
20.452 19.432 18.521 17.610 16.700 15.607
TC
21.979 20.724 19.604 18.484 17.364 16.021
15.0
SC
19.790 18.855 18.020 17.185 16.350 15.349
TC
26.144 24.250 22.559 20.869 19.178 17.149
18.0
SC
17.983 17.281 16.653 16.026 15.399 14.646
TC
28.087 25.895 23.938 21.981 20.024 17.676
19.4
SC
17.141 16.546 16.016 15.485 14.954 14.317
TC
28.920 26.657 24.637 22.616 20.596 18.171
20.0
SC
16.779 16.155 15.598 15.041 14.484 13.815
TC
31.696 29.197 26.965 24.733 22.502 19.824
22.0
SC
15.575 14.852 14.207 13.562 12.916 12.142
TC
34.473 31.737 29.294 26.850 24.407 21.476
26.7
24.0
SC
14.371 13.549 12.816 12.082 11.348 10.468
MODEL : MDB100B vs. MMC100B (cooling capacity)
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
26.307 25.150 24.116 23.083 22.049 20.809
13.9
SC
25.849 24.788 23.840 22.893 21.946 20.809
TC
28.451 26.971 25.649 24.328 23.006 21.420
15.0
SC
25.052 24.047 23.148 22.250 21.352 20.275
TC
34.298 31.938 29.831 27.724 25.616 23.088
18.0
SC
22.880 22.025 21.261 20.498 19.734 18.818
TC
37.027 34.256 31.782 29.308 26.834 23.866
19.4
SC
21.867 21.082 20.381 19.680 18.979 18.138
TC
38.196 35.310 32.733 30.157 27.580 24.488
20.0
SC
21.432 20.606 19.868 19.130 18.393 17.507
TC
42.094 38.824 35.904 32.985 30.065 26.561
22.0
SC
19.984 19.020 18.160 17.299 16.438 15.406
TC
45.992 42.338 39.075 35.812 32.550 28.634
26.7
24.0
SC
18.536 17.435 16.451 15.467 14.484 13.304
MODEL : MDB125B vs. MMC125B (cooling capacity)
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
30.218 29.333 28.542 27.751 26.960 26.011
13.9
SC
30.218 29.333 28.542 27.751 26.960 26.011
TC
34.065 32.436 30.982 29.528 28.074 26.329
15.0
SC
29.119 28.287 27.545 26.803 26.060 25.170
TC
44.554 40.900 37.637 34.374 31.111 27.195
18.0
SC
26.120 25.437 24.827 24.217 23.607 22.875
TC
49.450 44.850 40.743 36.635 32.528 27.600
19.4
SC
24.720 24.106 23.558 23.010 22.462 21.804
TC
51.548 46.731 42.430 38.130 33.829 28.668
20.0
SC
24.121 23.461 22.872 22.284 21.695 20.989
TC
58.541 53.002 48.056 43.111 38.165 32.231
22.0
SC
22.121 21.311 20.587 19.864 19.140 18.272
TC
65.534 59.273 53.682 48.092 42.501 35.793
26.7
24.0
SC
20.122 19.160 18.302 17.443 16.585 15.555
