MODEL : MDB250B2 vs. MMC125B x 2 (cooling capacity)
Outdoor DB, °C
Indoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
59.640 58.036 56.604 55.173 53.741 52.022
13.9
SC
59.640 58.036 56.604 55.173 53.741 52.022
TC
67.492 64.369 61.581 58.792 56.004 52.658
15.0
SC
57.600 56.072 54.707 53.342 51.977 50.339
TC
88.906 81.640 75.152 68.664 62.176 54.391
18.0
SC
52.037 50.713 49.531 48.349 47.168 45.749
TC
98.899 89.699 81.485 73.271 65.056 55.199
19.4
SC
49.441 48.213 47.116 46.020 44.923 43.607
TC
103.182 93.531 84.913 76.295 67.678 57.337
20.0
SC
48.328 46.991 45.797 44.603 43.410 41.977
TC
117.458 106.301 96.339 86.377 76.415 64.461
22.0
SC
44.619 42.919 41.401 39.883 38.365 36.543
TC
131.735 119.072 107.765 96.459 85.153 71.586
26.7
24.0
SC
40.910 38.847 37.005 35.162 33.320 31.109
MODEL : MDB300B3 vs. MMC100B x 3 (cooling capacity)
Outdoor DB, °C
Indoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
64.735 64.249 63.815 63.381 62.947 62.427
13.9
SC
64.735 64.249 63.815 63.381 62.947 62.427
TC
75.708 73.045 70.668 68.290 65.913 63.060
15.0
SC
65.618 64.444 63.396 62.348 61.300 60.043
TC
105.632 97.033 89.355 81.678 74.000 64.786
18.0
SC
68.023 64.974 62.252 59.530 56.807 53.540
TC
119.597 108.228 98.076 87.925 77.774 65.592
19.4
SC
69.146 65.222 61.718 58.214 54.710 50.506
TC
125.582 113.510 102.732 91.954 81.175 68.241
20.0
SC
69.627 65.296 61.428 57.560 53.692 49.051
TC
145.532 131.119 118.251 105.382 92.514 77.072
22.0
SC
71.231 65.541 60.460 55.380 50.299 44.202
TC
165.482 148.728 133.770 118.811 103.853 85.903
26.7
24.0
SC
72.835 65.786 59.493 53.199 46.905 39.353
MODEL : MDB400B4 vs. MMC100B x 4 (cooling capacity)
Outdoor DB, °C
Indoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0
TC
109.197 103.731 98.851 93.972 89.092 83.236
13.9
SC
109.197 103.731 98.851 93.972 89.092 83.236
TC
119.250 111.846 105.235 98.624 92.013 84.080
15.0
SC
105.797 100.378 95.539 90.701 85.863 80.057
TC
146.668 133.976 122.644 111.312 99.980 86.382
18.0
SC
96.523 91.231 86.506 81.781 77.057 71.387
TC
159.463 144.304 130.768 117.233 103.698 87.456
19.4
SC
92.195 86.963 82.291 77.619 72.947 67.341
TC
164.946 149.376 135.474 121.572 107.671 90.988
20.0
SC
90.340 85.090 80.402 75.714 71.027 65.401
TC
183.225 166.285 151.161 136.037 120.912 102.763
22.0
SC
84.158 78.848 74.107 69.366 64.625 58.936
TC
201.503 183.195 166.848 150.501 134.153 114.537
26.7
24.0
SC
77.975 72.606 67.812 63.017 58.223 52.470
