MODEL : MDB075DR vs. MMC075DR
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
21.490 20.339 19.311 18.284 17.256 16.023 15.201 14.790 14.379
13.9
SC
21.490 20.339 19.311 18.284 17.256 16.023 15.201 14.790 14.379
TC
22.869 21.531 20.335 19.140 17.945 16.511 15.555 15.077 14.599
15.0
SC
21.131 19.995 18.981 17.967 16.953 15.736 14.924 14.519 14.113
TC
26.631 24.781 23.129 21.477 19.825 17.843 16.521 15.861 15.200
18.0
SC
20.153 19.058 18.081 17.103 16.125 14.952 14.170 13.779 13.388
TC
28.386 26.298 24.432 22.567 20.702 18.464 16.972 16.226 15.480
19.4
SC
19.697 18.621 17.660 16.700 15.739 14.587 13.818 13.434 13.050
TC
29.139 26.990 25.071 23.153 21.234 18.932 17.397 16.629 15.862
20.0
SC
19.501 18.376 17.371 16.367 15.362 14.157 13.353 12.951 12.549
TC
31.647 29.298 27.201 25.104 23.007 20.490 18.812 17.974 17.135
22.0
SC
18.849 17.559 16.408 15.256 14.105 12.723 11.802 11.341 10.880
TC
34.155 31.606 29.330 27.055 24.779 22.048 20.228 19.318 18.407
26.7
24.0
SC
18.197 16.743 15.444 14.146 12.847 11.289 10.250 9.731 9.212
MODEL : MDB100DR vs. MMC100DR
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
25.456 24.303 23.273 22.243 21.213 19.977 19.153 18.741 18.329
13.9
SC
25.456 24.303 23.273 22.243 21.213 19.977 19.153 18.741 18.329
TC
27.447 26.002 24.712 23.421 22.131 20.583 19.550 19.034 18.518
15.0
SC
25.486 24.260 23.166 22.071 20.976 19.662 18.787 18.349 17.911
TC
32.876 30.636 28.636 26.636 24.636 22.236 20.636 19.836 19.035
18.0
SC
25.568 24.144 22.873 21.602 20.331 18.805 17.789 17.280 16.772
TC
35.410 32.799 30.467 28.136 25.805 23.007 21.142 20.209 19.277
19.4
SC
25.606 24.090 22.737 21.383 20.030 18.406 17.323 16.781 16.240
TC
36.496 33.779 31.353 28.928 26.502 23.592 21.651 20.681 19.711
20.0
SC
25.623 23.995 22.541 21.088 19.634 17.890 16.728 16.146 15.565
TC
40.115 37.047 34.307 31.567 28.828 25.540 23.349 22.253 21.157
22.0
SC
25.677 23.676 21.890 20.103 18.317 16.173 14.744 14.029 13.314
TC
43.734 40.314 37.261 34.207 31.153 27.489 25.046 23.824 22.603
26.7
24.0
SC
25.732 23.358 21.238 19.118 16.999 14.455 12.759 11.912 11.064
MODEL : MDB125DR vs. MMC125DR
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
32.960 31.103 29.445 27.786 26.128 24.138 22.812 22.148 21.485
13.9
SC
32.960 31.103 29.445 27.786 26.128 24.138 22.812 22.148 21.485
TC
34.622 32.614 30.822 29.029 27.236 25.084 23.650 22.933 22.216
15.0
SC
32.232 30.496 28.947 27.397 25.847 23.987 22.748 22.128 21.508
TC
39.156 36.737 34.577 32.417 30.257 27.665 25.937 25.073 24.209
18.0
SC
30.246 28.842 27.588 26.334 25.080 23.576 22.573 22.071 21.570
TC
41.271 38.660 36.329 33.998 31.666 28.869 27.004 26.071 25.139
19.4
SC
29.319 28.070 26.954 25.838 24.723 23.384 22.491 22.045 21.599
TC
42.178 39.496 37.100 34.705 32.310 29.436 27.520 26.561 25.603
20.0
SC
28.922 27.594 26.407 25.221 24.035 22.612 21.663 21.189 20.714
TC
45.200 42.279 39.671 37.063 34.455 31.326 29.239 28.196 27.153
22.0
SC
27.598 26.007 24.586 23.165 21.744 20.039 18.903 18.334 17.766
TC
48.223 45.063 42.242 39.422 36.601 33.216 30.959 29.831 28.702
26.7
24.0
SC
26.274 24.420 22.764 21.109 19.453 17.467 16.142 15.480 14.818
MODEL : MDB125DR2 vs. MLC061CR x 2
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
31.653 29.808 28.161 26.514 24.866 22.890 21.572 20.913 20.254
13.9
SC
31.653 29.808 28.161 26.514 24.866 22.890 21.572 20.913 20.254
TC
33.516 31.413 29.536 27.659 25.781 23.529 22.027 21.276 20.525
15.0
SC
30.997 29.359 27.896 26.434 24.971 23.216 22.046 21.460 20.875
TC
38.597 35.791 33.287 30.782 28.277 25.271 23.267 22.265 21.264
18.0
SC
29.210 28.135 27.175 26.216 25.256 24.105 23.337 22.953 22.569
TC
40.968 37.834 35.037 32.239 29.442 26.084 23.846 22.727 21.608
19.4
SC
28.375 27.564 26.839 26.114 25.389 24.519 23.939 23.650 23.360
TC
41.984 38.785 35.929 33.073 30.218 26.790 24.506 23.363 22.221
20.0
SC
28.018 27.093 26.267 25.441 24.615 23.624 22.963 22.633 22.302
TC
45.371 41.955 38.905 35.854 32.804 29.144 26.704 25.484 24.264
22.0
SC
26.826 25.523 24.360 23.197 22.034 20.638 19.708 19.243 18.777
TC
48.758 45.124 41.880 38.635 35.391 31.498 28.902 27.604 26.307
26.7
24.0
SC
25.634 23.954 22.454 20.953 19.453 17.653 16.453 15.853 15.253
