McQuay MDB100D User Manual

30
MODEL : MDB150DR vs. MMC150DR
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
44.450 41.664 39.175 36.687 34.199 31.213 29.223 28.228 27.232
13.9
SC
44.450 41.664 39.175 36.687 34.199 31.213 29.223 28.228 27.232
TC
45.766 43.029 40.586 38.142 35.699 32.767 30.812 29.835 28.857
15.0
SC
42.134 39.818 37.749 35.680 33.612 31.130 29.475 28.647 27.820
TC
49.354 46.754 44.432 42.111 39.789 37.003 35.146 34.217 33.289
18.0
SC
35.818 34.783 33.859 32.934 32.010 30.901 30.161 29.792 29.422
TC
51.028 48.492 46.227 43.962 41.698 38.980 37.168 36.262 35.356
19.4
SC
32.871 32.434 32.043 31.653 31.263 30.794 30.482 30.326 30.170
TC
51.746 49.168 46.865 44.563 42.261 39.498 37.656 36.735 35.814
20.0
SC
31.608 31.178 30.795 30.412 30.029 29.569 29.262 29.109 28.955
TC
54.138 51.420 48.992 46.565 44.138 41.225 39.283 38.312 37.341
22.0
SC
27.397 26.994 26.634 26.274 25.915 25.483 25.195 25.051 24.907
TC
56.530 53.672 51.119 48.567 46.014 42.951 40.909 39.888 38.867
26.7
24.0
SC
23.186 22.810 22.473 22.137 21.801 21.397 21.128 20.994 20.859
MODEL : MDB150DR2 vs. MMC075DR x 2
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
42.593 40.373 38.390 36.407 34.425 32.046 30.460 29.667 28.874
13.9
SC
42.593 40.373 38.390 36.407 34.425 32.046 30.460 29.667 28.874
TC
45.429 42.817 40.485 38.153 35.821 33.022 31.157 30.224 29.291
15.0
SC
41.953 39.746 37.776 35.806 33.836 31.471 29.895 29.107 28.319
TC
53.163 49.484 46.199 42.913 39.628 35.686 33.057 31.743 30.429
18.0
SC
40.208 38.039 36.102 34.165 32.229 29.905 28.355 27.581 26.806
TC
56.773 52.595 48.865 45.135 41.405 36.928 33.944 32.452 30.960
19.4
SC
39.393 37.242 35.321 33.400 31.479 29.174 27.637 26.868 26.100
TC
58.320 54.013 50.168 46.323 42.478 37.863 34.787 33.249 31.711
20.0
SC
39.044 36.785 34.768 32.751 30.734 28.313 26.700 25.893 25.086
TC
63.476 58.740 54.512 50.283 46.054 40.980 37.597 35.906 34.214
22.0
SC
37.881 35.263 32.925 30.588 28.251 25.446 23.576 22.641 21.706
TC
68.632 63.467 58.855 54.243 49.631 44.097 40.407 38.562 36.718
26.7
24.0
SC
36.717 33.741 31.083 28.425 25.768 22.578 20.452 19.389 18.326
MODEL : MDB200DR2 vs. MMC100DR x 2
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
50.117 47.977 46.067 44.156 42.246 39.953 38.425 37.660 36.896
13.9
SC
50.117 47.977 46.067 44.156 42.246 39.953 38.425 37.660 36.896
TC
54.258 51.501 49.040 46.579 44.118 41.165 39.197 38.212 37.228
15.0
SC
50.336 48.018 45.948 43.878 41.809 39.325 37.669 36.841 36.013
TC
65.550 61.112 57.150 53.188 49.226 44.471 41.302 39.717 38.132
18.0
SC
50.934 48.129 45.625 43.120 40.616 37.611 35.608 34.606 33.604
TC
70.820 65.597 60.935 56.272 51.609 46.014 42.284 40.419 38.554
19.4
SC
51.213 48.181 45.474 42.767 40.060 36.811 34.646 33.563 32.480
TC
73.078 67.626 62.759 57.892 53.024 47.183 43.289 41.342 39.395
20.0
SC
51.332 48.058 45.135 42.212 39.289 35.781 33.442 32.273 31.104
TC
80.606 74.390 68.840 63.290 57.740 51.080 46.641 44.421 42.201
22.0
SC
51.730 47.649 44.006 40.362 36.718 32.345 29.430 27.973 26.515
TC
88.134 81.154 74.921 68.689 62.457 54.978 49.992 47.499 45.006
26.7
24.0
SC
52.129 47.241 42.876 38.512 34.148 28.910 25.419 23.673 21.927
MODEL : MDB250DR2 vs. MMC125DR x 2
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
63.217 60.071 57.263 54.455 51.647 48.277 46.030 44.907 43.783
13.9
SC
63.217 60.071 57.263 54.455 51.647 48.277 46.030 44.907 43.783
TC
67.082 63.521 60.342 57.163 53.984 50.169 47.625 46.354 45.082
15.0
SC
62.301 59.285 56.592 53.899 51.206 47.975 45.820 44.743 43.666
TC
77.624 72.930 68.739 64.549 60.358 55.329 51.977 50.300 48.624
18.0
SC
59.804 57.140 54.762 52.384 50.005 47.151 45.249 44.298 43.346
TC
82.543 77.321 72.658 67.995 63.333 57.737 54.007 52.142 50.277
19.4
SC
58.638 56.139 53.908 51.676 49.445 46.767 44.982 44.090 43.197
TC
84.651 79.224 74.378 69.532 64.686 58.871 54.995 53.056 51.118
20.0
SC
58.139 55.420 52.992 50.565 48.137 45.224 43.282 42.310 41.339
TC
91.679 85.568 80.112 74.655 69.199 62.651 58.286 56.104 53.921
22.0
SC
56.474 53.023 49.941 46.859 43.777 40.078 37.613 36.380 35.147
TC
98.707 91.912 85.845 79.778 73.712 66.431 61.578 59.151 56.725
26.7
24.0
SC
54.809 50.625 46.889 43.153 39.417 34.933 31.944 30.450 28.955
