McQuay MDS030AR User Manual

-17-
Design & installation Guide For McQuay MDS Multi System
Notes:
The nominal cooling capacity is gotten in the return air temperature of 27 /19 , and the ambient temperature of 35 /24 .
The nominal heating capacity is gotten in the return air temperature of 20 /15 , and the ambient temperature of 7 /6 .
The specification parameters may change with the product improvement; Please take the parameters listed in the nameplate
of the unit as the reference parameter.
Notes:
The nominal cooling capacity is gotten in the return air temperature of 27 /19 , and the ambient temperature of 35 /24 .
The nominal heating capacity is gotten in the return air temperature of 20 /15 , and the ambient temperature of 7 /6 .
The specification parameters may change with the product improvement; Please take the parameters listed in the nameplate
of the unit as the reference parameter.
Model Unit MDS050A MDS050AR MDS060A MDS060AR
Nominal cooling capacity kW 12.5 12.5 15 15
Nominal heating capacity kW - 13.5 - 17
Power supply 380V/3N~/50Hz
Dimension (L x W x H) mm 1058x430x1044 1058x430x1247
Weight kg 117 120 123 130
Cooling rated power input kW 4.4 4.4 5.0 5.0
Cooling rated current A 8.4 8.4 9.6 9.6
Heating rated power input kW - 4.2 - 4.23
Heating rated current A - 8.0 - 8.8
Refrigerant R22
Type of connecting pipe
Liquid pipe Copper flare fitting & nipple joint
Gas pipe Copper flare fitting & nipple joint
Piping size
Liquid pipe
(mm/in) 9.52(3/8 )
Gas pipe
(mm/in) 19.05(3/4 )
1.6.6 MDS-A Specification(Outdoor Unit)
Model Unit MDS030A MDS030AR MDS040A MDS040AR MDS050A MDS050AR MDS060A MDS060AR
Nominal cooling capacity kW 8.5 8.5 10 10 12.5 12.5 14.5 14.5
Nominal heating capacity kW - 9.0 - 11.5 - 13.5 - 16.5
Power supply 220V~/50Hz
Dimension (L x W x H) mm
Weight
kg 82 85 112 115 117 120 123 130
Cooling rated power input
kW 3.0 3.0 3.5 3.6 4.4 4.4 5.0 5.0
Cooling rated current
A 13.6 13.6 15.9 15.9 20 20 22.8 22.8
Heating rated power input
kW - 2.5 - 3.4 - 4.2 - 4.2
Heating rated current
A- 11.4 - 15.5 - 19 - 20.3
Refrigerant
R22
Type of connecting pipe copper flare fitting & nipple joint
Liquid pipe (mm/in)
Gas pipe (mm/in)
840x408x900 1058x430x1044 1058x4230x1247
9.52(3/8
)9.52(3/8 )9.52(3/8 )9.52(3/8 )
15.88(5/8
) 19.05(3/4 ) 19.05(3/4 ) 19.05(3/4 )
Piping size
