-25-
Design & installation Guide For McQuay MDS Multi System
1.10 Outline of Outdoor Units
1.10.1 MDS030A(R)
1.10.2 MDS040A(R) MDS050A(R) MDS060A(R)
Unit: mm
Unit: mm
Model H1 H2
MDS040A(R) 1024 1044
MDS050A(R) 1024 1044
MDS060A(R) 1222 1242
840
590
900
460
20
4-12x18
125
378
318
408
330
240
124
50
6760
390
94
816
1006
H1
H2
128
67
11594
356
430
4-15
