-26-
Design & installation Guide For McQuay MDS Multi System
1.10.3 MDS080B(R) MDS100B(R) MDS120B(R) MDS150B(R)
B
45
265
1575
A
Amplify here A-A
A-A
8-14x20 screw hole
(for setting)
170
845 877
16
840
14
20
1840
539
1.10.4 MDS180B(R) MDS200B(R) MDS220B(R) MDS240B(R)
D
101 101
845
16
45 45
265
1575
1840
CC
170 170
16
4-14x20 screw hole
(for setting)
1.10.5 MDS260/280/300B(R) are Combined Units,Made up by a Master Unit and a Slave Unit
Unit: mm
Model A B
MDS080B(R) 900 990
MDS100B(R) 900 990
MDS120B(R) 900 990
MDS150B(R) 1200 1290
Model Master unit+Slave unit D
MDS260B(R) MDS120B(R)+MDS150B(R)S 990+10+1290
MDS280B(R) MDS150B(R)+MDS130B(R)S 1290+10+1290
MDS300B(R) MDS150B(R)+MDS150B(R)S 1290+10+1290
Unit: mm
Model C D
MDS180B(R) 950 1990
MDS200B(R) 950 1990
MDS220B(R) 950 1990
MDS240B(R) 950 1990
