R410A 60Hz 16 SEER Universal Outdoor Series Technical Manual
11
Model
36K
60K
820023100002
820023100001
MQC164036CFC216B
MQC164060CFC216B
Indoor power supply
V/Ph/Hz
208~230/1/60
208~230/1/60
Cooling
Capacity
kW
10.5
16
Input
W
240
320
Rated current
A
1.0
1.5
Max. power input
W
4000
6800
Max. current input
A
19.0
35.0
Indoor fan motor
Model
YSK110-180LD-4P2
YSK110-85LD-4P2
Brand
XINJUN
KANGBAO
Power output
W
180
85*2
Capacitor
μF
5
5
Speed
r/min
1330/1230/1130
1560/1430/1300
Insulation class
B
B
Indoor coil
Number of rows
3
4
Tube pitch(a) x row pitch(b)
mm
25*21.65
22*19.05
Fin spacing
mm
1.7
1.4
Fin type
Hydrophilic
Hydrophilic
Tube outside dia. and type
mm
9.52
7.94
Inner grooved
Inner grooved
Coil length x height x width
mm
982/250/65
1360/252/70
Number of circuits
5
4
Indoor air flow(High speed)
m
3
/h
1800
2000
Indoor noise level
dB(A)
64
65
Indoor unit
Dimension(W×H×D)
mm
1250×675×235
1670×675×235
Packing(W×H×D)
mm
1380×765×325
1750×765×325
Gross/Net weight
kg
38/33
49/43
Max pressure
MPa
4.5
4.5
Refrigerant type
R410A
R410A
Refrigerant piping
Liquid side/Gas side
mm
Ф9.52/Ф15.88
Ф9.52/Ф15.88
Drainage pipe
mm
DN25
DN25
Standard controller
Wired control
