OM 135 PFS 155C - 315C 17
Component Description
Microprocessor Control Board (MCB1)
The Model 280 Microprocessor Control Board contains the electronic hardware and software required
to monitor and control the unit. It receives input from the
ADI Board and sends commands to the Output Board to
maintain the unit's optimum operating mode for the current
conditions. Status lights are mounted on the control board
to indicate the operating condition of the microprocessor.
