OM 135 PFS 155C - 315C 39
Menu 18, Service Testing
Press the "NEXT MENU" key and Menu 18 will be displayed. This menu is pass word protected and requires the
service password.
Item
Screen Line Display Field Range
1 1 Output #0=Off 1 Off-On
EXV Position=0 2 0-999
2 Output #1=Off 1 Off-On
Output #5=Off 2 Off-On
3 Output #2=Off 1 Off-On
2 1 Output #6=Off 1 Off-On
Output #9=Off 2 Off-On
2 Output #7=Off 1 Off-On
Output #10=Off 2 Off-On
3 Output #8=Off 1 Off-On
Output #11=Off 2 Off-On
3 1 Output #12=Off 1 Off-On
Output #15=Off 2 Off-On
2 Output #13=Off 1 Off-On
Output #16=Off 2 Off-On
3 Output #14=Off 1 Off-On
Output #17=Off 2 Off-On
4 1 Output #18=Off 1 Off-On
Output #21=Off 2 Off-On
2 Output #19=Off 1 Off-On
Output #22=Off 2 Off-On
3 Output #20=Off 1 Off-On
Output #23=Off 2 Off-On
5 1 DI #0-7=00000000 1
2 DI #8-15=00000000 1
3 DI #16-23=00000000 1
6 1 Voltage = 0.00 Vdc 1
AI #23=0 2
2 AI #21 =0 1
3 AI #22 =0 1
Menu 19, Chiller Setup
Press the "NEXT MENU" key and Menu 19 will be displayed. This menu is password protected and requires the
operator password. Changing the values in this menu can cause network communications failure.
Item
Screen Line Display Field Range
1 1 Config=L2-TTY-Slave 1 L1-TTY-Mastr
L1-TTY-TTY
L2-Mastr-Slv
L2-TTY-Slave
L3-TTY-Slave
IDENT=FLU2E-01-I 2
2 Port A Baud =9600 1 1200
2400
9600
Chiller Only 2 Only
/Templifier
Menu continued on next page
