1-2
Recommended mounting plate retention
spots (7 spots in all)
D
B
G
H
J
LM
A
K
F
I
G
F
E
Through the wall
hole Ø 65mm
Drain hose
position
Liquid pipe end
Gas pipe end
INSTALLATION PLATE WM20/25J/JR
All dimensions are in mm/(in)
Dimension A B C D E F G H I J K L M
09/10/15J/JR 800 288 206 166 184 42 46 55 56 154 182 263 52
(31.5) (11.3) (8.1) (6.5) (7.2) (1.7) (1.8) (2.1) (2.2) (6.1) (7.2) (10.4) (2.0)
20/25J/JR 1065 310 224 190 173 61 40 45 48 91 219 580 45
(41.9) (12.2) (8.8) (7.5) (6.8) (2.4) (1.6) (1.8) (1.9) (3.6) (8.6) (22.8) (1.8)
Outdoor Unit [(5)SL Series]
All dimensions are in mm/(in)
3
(0.1)
B
EF
NC N
KLL
M
30
(1.2)
A
D
19
(0.7)
C
GH
IJ
O
80
(3
.
1)
65
(2
.
6)
Dimension A B C D E F G H I J K L M N O
09C/CR 600 475 245 418 177 35 93 81 83 55 398 101 97 17 22
(23.6) (18.7) (9.6) (16.4) (6.9) (1.3) (3.6) (3.1) (3.2) (2.2) (15.6) (3.9) (3.8) (0.6) (0.8)
10/15C/CR 700 521 250 485 175 36 95 93 86 68 441 130 111 15 18
(27.5) (20.5) (9.8) (19.1) (6.8) (1.4) (3.7) (3.6) (3.3) (2.6) (17.3) (5.1) (4.3) (0.5) (0.7)
1 IM-WMJ-1207(2)_EN 11/20/09, 4:32 PM2
