McQuay R08019031289A User Manual

1-3
English
Dimension A B C D E F G H I J K L M N O
20C/CR 855 628 328 508 181 44 93 149 101 113 603 126 164 17 49
(33.7) (24.7) (12.9) (20.0) (7.1) (1.7) (3.7) (5.9) (4.0) (4.4) (23.7) (5.0) (6.4) (0.7) (1.9)
25C/CR 855 730 328 513 182 44 93 149 101 113 603 126 164 17 47
(33.7) (28.7) (12.9) (20.2) (7.2) (1.7) (3.7) (5.9) (4.0) (4.4) (23.7) (5.0) (6.4) (0.7) (1.9)
Dimension P Q R S T
20C/CR 32 3 23 73 75
(1.3) (0.1) (0.9) (2.9) (3.0)
25C/CR 32 3 23 73 75
(1.3) (0.1) (0.9) (2.9) (3.0)
B
A
Q
R
ST
DO
KLL
CN
P
M
N
FE
C
GH
IJ
FOR SL25C/CR
ONLY
All dimensions are in mm/(in)
Outdoor Unit [SL Series]
1 IM-WMJ-1207(2)_EN 11/20/09, 4:32 PM3
