IM708 3
Introduction
General Description
Models SWP018 through 105 are factory assembled, refrig-
erant charged and tested, water cooled packaged air condi-
tioning units designed for ducted applications.
Each unit contains multiple hermetic compressors, water
cooled condensers, multi-circuit evaporator, thermal expan-
sion valves, interconnecting refrigerant piping, forward
curved centrifugal fan, belt drive, fan motor, pleated filters
and all necessary operating and safety controls.
All rigging, installation, power and control wiring external to
the unit, and condenser water and condensate piping are the
responsibility of the installer.
The MicroTech II self-contained unit controller is standard
equipment. For a detailed description of the MicroTech II
components, input/output configurations, field wiring
options and requirements, and service procedures, refer to
Bulletin No. IM 710, "MicroTech II Self-contained Unit
Controller." For a description of operation and information
on using and programming the MicroTech II unit controller,
refer to the appropriate operation manual (see Table 1).
Table 1: Self-contained unit operation manual literature
Inspection
When the equipment is received, all items should be care-
fully checked against the bill of lading to insure a complete
shipment. The shipping receipt should not be signed until all
items have been accounted for. All units should be carefully
inspected for damage upon arrival. All shipping damage
should be reported to the carrier and a claim filed. The unit
serial plate should be checked before unloading the unit to be
sure that it agrees with the power supply available.
UNIT CONTROL
CONFIGURATION
OPERATION MANUAL
BULLETIN NUMBER
Variable Air Volume (VAV)
Discharge Air Control (DAC)
OM711
Constant Air Volume
Space Comfort Control (SCC)
OM712
Constant Air Volume
Discharge Air Control (DAC)
OM711
Nomenclature
SWP-055-D
Self-contained
Water cooled
Plenum discharge
Vintage
Nominal tons
