McQuay SWP 055

40 IM708
START-UP
A. Does the unit start & perform per sequence of operation as stated in IM Bulletin? Yes No
B. Does the fan rotate in the right direction? Yes No
C. Condenser inlet water temperature Deg. F _____
D. Condenser outlet water temperature Deg. F. _____
E. Number of Compressors Operating Deg. F. _____
F. Return air temperature Deg. F. _____
G. Mixed air temperature Deg. F. _____
H. Supply air temperature Deg. F. _____
I. Compressor Readings:
J. Electrical Heat Readings (When installed):
FLA amps (nameplate)
Reading
Compressor
#1
Compressor
#2
Compressor
#3
Compressor
#4
Compressor
#5
Compressor
#6
Suction Pressure, psig
Discharge Pressure, psig
Superheat Setting @ TXV
Bulb, Deg. F
Compressor RLA (name
plate)
Current, Line L1, amps
Current, Line L2, amps
Current, Line L3, amps
Reading
68KW Heat, 230v or 208v Only
@ Contactor M11 @ Contactor M12 @ Contactor M15 @ Contactor M16
Current, Line Ll, amps
Current, Line L2, amps
Current, Line L3, amps
