Page 2 / IM 447
NOTE: For illustration purposes only. Not all options available with all models.
Please consult a McQuay Sales Representative for specific availability.
McQuay WSHP Product Nomenclature
W WDA 1 009 E Z
Product Category
W = WSHP
Product Identifier
See box below
Design Series
1 = A Design
2 = B Design
3 = C Design
4 = D Design
5 = E Design
Nominal Capacity
007 = 7,000
009 = 9,000
012 = 12,000
015 = 15,000
019 = 19,000
Coil Options
(None)
Voltage
A = 115-60-1
E = 208/230-60-1
J = 265-60-1
M = 230-50-1
WDA = Flat Top Wall mtd./DDC Controls/Low Sill
WDB = Slope Top Wall mtd./DDC Controls/Low Sill
WDD = Slope Top Wall mtd./DDC Controls/Low Sill/Chassis Only
WDE = Slope Top Wall mtd./DDC Controls/Low Sill/Chassis Only
WDF = Flat Top Wall mtd./DDC Controls/High Sill
WDG = Flat Top Wall mtd./DDC Controls/High Sill/Less Board
WDH = Slope Top Wall mtd./DDC Controls/High Sill/Less Board
WDS = Slope Top Wall mtd./DDC Controls/High Sill
WLA = Slope Top Wall mtd./Mark IV/High Sill/Low Limit, NSB & Override
WLB = Flat Top Wall mtd./Mark IV/Low Sill/Low Limit, NSB & Override
WLC = Slope Top Wall mtd./Mark IV/Low Sill/Low Limit, NSB & Override
WLL = Flat Top Wall mtd./Mark IV/High Sill/Low Limit, NSB & Override
McQuay WSHP Product Identifiers
WMA = Slope Top Wall mtd./Mark IV/Low Sill
WMB = Flat Top Wall mtd./Mark IV/Low Sill
WMC = Flat Top Wall mtd./Mark IV/High Sill/Chassis Only
WMD = Flat Top Wall mtd./Mark IV/Low Sill/Chassis Only
WME = Flat Top Wall mtd./Mark IV/High Sill/European Spec.
WMF = Flat Top Wall mtd./Mark IV/High Sill
WMG = Slope Top Wall mtd./Mark IV/High Sill/Chassis Only
WMH = Slope Top Wall mtd./Mark IV/Low Sill/Chassis Only
WMJ = Flat Top Wall mtd./Mark IV/Low Sill/European Spec.
WMK = Flat Top Wall mtd./Mark IV/High Sill/Chassis Only/European Spec.
WML = Flat Top Wall mtd./Mark IV/Low Sill/Chassis Only/European Spec.
©McQuay International 2006
The information in this catalog supersedes and replaces previous (bulletins) with regards to McQuay Terminal Air Conditioning products.
Illustrations cover the general appearance of McQuay products at the time of publication and McQuay reserves the right to make changes in
design and construction at anytime without notice.
Model Nomenclature
