OM WGS-5 WGS 130A to 190A 11
Figure 4, Inner (Power) Panel (Optional Single-Point Power with Disconnect Switches
Shown)
Circ#1 Solid State Starter
Circ#2 Solid State Starter
SSS1 Bypass Contactor
SSS2 Bypass Contactor
Secondary Fuses
Circ#1 Circuit Breaker
Circ#2 Circuit Breaker
Unit Disconnect Switch
W/ External Handle
External Disconnect Handle
T1, Supply Voltage to
120V Transformer
Primary Fuses
Outside (Microprocessor) Panel
