View Circuit Status

In the following VIEW CIR screens, the N field indicates which circuit (#1, #2) is being

viewed. Certain screens located in the circuit controller are also displayed here on the unit

controller for convenience.

VIEW CIR N STATUS(1)

{Circuit Status}

Slide Pos= 000.0%

Slide Target=000.0%

Circuit Status will display one of the following:

Off:Ready Off:Cycle Timer Off:Low OAT Lock

Off:Keypad Disable Off:Pumpdown Switch Off:Alarm

Off:Test Mode EXV Preopen Run:Pumpdown

Run:Normal Run:LWT PullDn Limit Run:Unit Cap Limit

Run:High LWT Limit Run:Evap Press Low Run:Lift Press High

Off:pLAN failure

VIEW CIR N STATUS(2)

Hours = XXXXX

Starts = XXXXX

VIEW CIR STATUS (3)

Current (amps)

L1 L2 L3 Avg

XXX XXX XXX XXX

VIEW CIR STATUS (4)

Voltage

L1-2 L2-3 L3-1 Avg

XXX XXX XXX XXX

VIEW CIR STATUS (5)

PF= 0.XX %RLA=XXX.X

KW= XXX

KVA= XXX

View Refrigerant

In the following VIEW REFR screens, the N field indicates which circuit (#1, #2) is being

viewed.

VIEW REFR CIR N (1)

Evap Press=XXX.X p

Cond Press=XXX.X psi
