88 WGS 130A to 190A OM WGS-5
VIEW < UNIT
< CIR STATUS
<REFRIGERANT
< FANS
Fan data is available only when unit is configured as air-cooled.
Set menu:
SET <COMPRESSOR SPs
< EXV SPs
< FAN SPs
<SENSOR OFFSETS
Fan setpoints are available only when unit is configured as air-cooled.
Screen Definitions – VIEW
View Unit Status
Water cooled: Air cooled:
VIEW UNIT (1) VIEW UNIT (1)
{Unit status} {Unit status}
Evap pump = {State} Evap pump = {State}
Cond pump = {State}
Unit Status will display one of the following:
Auto Off:Ice Mode Timer Off:All Cir Disabled
Off:Unit Alarm Off:Keypad Disable Off:Remote Switch
Off:BAS Disable Off:Unit Switch Off:Test Mode
Auto:Wait for load Auto:Cond Recirc Auto:Evap Recirc
Auto:Wait Cond Flow Auto:Wait Evap Flow Auto:Pumpdown
Pump states include Off, Start, and Run. The condenser pump state is visible only for
water-cooled operation.
VIEW UNIT (2)
Evap LWT= XXX.XF
Active SP= XX.XF
LWT pulldn= XX.XF/m
View Circuit Status
VIEW CIR STATUS (1)
{Circuit Status}
Slide Pos= XXX.X%
Slide Target= XXX.X%
Circuit Status will display one of the following:
Off:Ready Off:Cycle Timer Off:Low OAT Lock
Off:Keypad Disable Off:Pumpdown Switch Off:Alarm
Off:Test Mode EXV Preopen Run:Pumpdown
Run:Normal Run:LWT PullDn Limit Run:Unit Cap Limit
Run:High LWT Limit Run:Evap Press Low Run:Lift Press High
Off:pLAN failure Off:Stage Up Delay
To Next Page
