12 IM 1128-2
Figure 6, Motor Drain Line
R331311305C0100
20" MOTOR REF. DRAIN
CONNECTION
(REAR VIEW)
15" MOTOR REF. DRAIN
CONNECTION
(REAR VIEW)
MOTOR HOUSING
DRAIN LINE
MOTOR DRAIN LINE
(NOT ALL VARIATIONS SHOWN)
MECHANICAL
BREAK POINT
