TECHNICAL CHARACTERISTICS CUTE/THEMA Model AIR
Nominal output power 8 kW (6880 kcal/h)
Minimum output power 2,4 kW (2064 kcal/h)
Eciency at Max 90,5%
Eciency at Min 90,0%
Temperature of exhaust smoke at Max 170 °C
Temperature of exhaust smoke at Min 100 °C
Particulate /OGC / Nox (13%O
2
) <13 mg/Nm3 - 5 mg/Nm3 - 107 mg/Nm3
CO at 13% O
2
at Min and at Max 0,060 – 0,018%
CO
2
at Min and at Max 4,5% - 9,0%
Recommended draught at Max power**** 0,10 mbar - 10 Pa****
Minimum draw allowed for minimum power 0,0 mbar - 0 Pa
Smoke mass 6,2 g/sec
Hopper capacity 20 litres
Type of pellet fuel Pellet diameter 6-8 mm and size 5/30 mm
Pellet hourly consumption Min ~ 0,7 kg/h* - Max ~ 1,8 kg/h*
Autonomy At min ~ 20 h* - At max ~ 7 h*
Heatable volume m
3
172/40 – 197/35 – 229/30 **
Combustion air inlet Ø 50 mm
Smoke outlet Ø 80/100*** mm
Air inlet 80 cm
2
Rated electrical power (EN 60335-1) 55 W (Max 400 W)
Supply voltage and frequency 230 Volt / 50 Hz
Net weight 130 kg
Weight with packaging 140 kg
Distance from combustible material (rear\sides\oor) 50/50/0 mm
Distance from combustible material (ceiling\front) 800/800 mm
* Data that may vary depending on the type of pellets used
** Volume that can be heated, according to the power requirement per m
3
(respectively 40-35-30 Kcal/h per m
3
)
***Using the adapter supplied with the product
**** Value recommended by the manufacturer (non-binding) for the optimal operation of the product
Head according to EN 14785 in agreement with the EU Building Products Regulation (EU 305/2011).
