v
S
t
v
t
S
P
20
6-INSTALLATION AND ASSEMBLY
DISASSEMBLING THE SIDE CLADDING
In the event the side has to be removed, proceed as follows:
• Open the door ”P”
• Remove the two screws “v” at the front of the stove
• Remove the two screws “t” at the back of the stove
• Pull out the panel “S”
Proceed with the same system for the other panel as well.
