6-INSTALLATION AND ASSEMBLY
Technical Dept. - All rights reserved - Reproduction is prohibited
Therefore, the end user is responsible for product storage, disposal or possible recycling in compliance with the relative applicable laws in
force. Do not store the stove unit or its cladding without their packaging.
Position the stove and connect it to the ue pipe.
If the stove needs to be connected to an outlet pipe which goes through the rear wall (to connect to the ue), take utmost care to make
sure that the joint is not forced.
If the stove smoke outlet is forced or used improperly to lift it or position it, the operation of the stove can be
damaged irreparably.
THEMA STOVE CERAMIC/STEATITE PACKAGING
The front panel of ceramic or soapstone will have a packaged separately and will then be installed on the stove
1. TURN THE FEET CLOCKWISE TO LOWER THE STOVE
2. TURN THE FEET COUNTERCLOCKWISE TO LIFT THE STOVE
