PELLET STOVES Chapter 3
INSTALLATION AND USE MANUAL
page 20
Installation and assembly Technical service - Rights reserved MCZ GROUP S.p.A. - Reproduction prohibited
FOR THE HYDRAULIC PIPE OUTPUT DRAWINGS, SEE
PAGES 31-32
3.1.9. Technical characteristics
Technical characteristics Ego Hydro / Star Hydro
Nominal thermal power
11,6 kW (9976 kcal/h)
Nominal output power (H2O):
10,0 kW (8600 kcal/h)
Minimum output power 3,6 kW (3096 kcal/h)
Minimum output power (H20) 2,5 KW (2150 kcal/h)
Yield at maximum
91,5%
Yield at minimum
96,0%
Temperature of exhaust smoke at maximum
140°C
Temperature of exhaust smoke at minimum
70°C
Particulate/OGC / Nox (13%O2)
11 mg/Nm3 - 3 mg/Nm3 - 168 mg/Nm3
CO at 13%O
²
at minimum and maximum
0.034 — 0.011%
CO
2
at minimum and maximum
6.7% – 8.7%
Mass of smoke
9,4 g/sec
Maximum water pressure 2.5 bar - 250 kPa
Recommended draught at Max*** power
0.10 mbar – 10 Pa***
Minimum draft allowed at minimum power
0.00 mbar – 0 Pa
Hopper capacity 37 litres
Fuel pellet type Pellet diameter 6-8 mm. Length range 5-30 mm
Pellet consumption per hour
Min ~ 0,8 kg/h * Max. ~ 2,5 kg/h *
Operating time between re-fuelling
Al min ~ 36 h * Al max. ~ 10 h *
Heatable volume m
3
249/40 – 285/35 – 333/30 **
Combustion air inlet External diameter 50 mm.
Smoke outlet External diameter 80 mm.
Air intlet
80 Cm
2
Rated electrical power (EN 60335-1) 120 W (Max 420 W)
Power supply frequency and voltage 230 Volts / 50 Hz
Net weight 175 kg
Weight with packaging 185 Kg
Distance from combustible material (rear):
100 mm
Distance from combustible material (sides):
100 mm
* Data that may vary depending on the type of pellets used
** Volume that can be heated, according to the power requirement per m
3
(respectively 40-35-30 Kcal/h per m
3
)
***Value recommended by the manufacturer (non-binding) for optimal product operation
Tested according to EN 14785 in accordance with European regulation for Construction Products (EU
305/2011).
