Technical characteristics Suite 22 Hydro / Club 22 Hydro / Musa 22 Hydro
Nominal thermal power
22,3 kW (19178 kcal/h)
Nominal output power (H2O):
18,0 KW (15480 kcal/h)
Minimum output power 4,4 kW (3784 kcal/h)
Minimum output power (H20) 3,0 KW (2580 kcal/h)
Yield at maximum 92,5%
Yield at minimum 95,0%
Temperature of exhaust smoke at maximum 160°C
Temperature of exhaust smoke at minimum 71°C
Particulate/OGC / Nox (13%O2)
2 mg/Nm3 – 0,2 mg/Nm3 - 132 mg/Nm3
CO at 13%O
²
at minimum and maximum 0.040 — 0.012%
CO
2
at minimum and maximum 7,03% – 12,49%
Maximum water pressure 2.5 bar - 250 kPa
Mass of smoke 12,6 g/sec
Recommended draught at Max*** power
0.10 mbar – 10 Pa***
Minimum draft allowed at minimum power
0.00 mbar – 0 Pa
Hopper capacity 44 litres
Fuel pellet type Pellet diameter 6-8 mm. Length range 5-30 mm
Pellet consumption per hour Min ~ 0,9 kg/h * Max. ~ 4,9 kg/h *
Operating time between re-fuelling Al min ~ 28 h * Al max. ~ 5 h *
Heatable volume m
3
481/40 – 550/35 – 642/30 **
Combustion air inlet External diameter 50 mm.
Smoke outlet External diameter 80 mm.
Air intlet
80 Cm
2
Rated electrical power (EN 60335-1) 120 W (Max 420 W)
Power supply frequency and voltage 230 Volts / 50 Hz
Net weight 190 kg
Weight with packaging 200 Kg
Distance from combustible material (rear):
100 mm
Distance from combustible material (sides):
100 mm
* Data that may vary depending on the type of pellets used
** Volume that can be heated, according to the power requirement per m
3
(respectively 40-35-30 Kcal/h per
m
3
)
***Value recommended by the manufacturer (non-binding) for optimal product operation
Tested according to EN 14785 in accordance with European regulation for Construction Products
(EU 305/2011).
