MDB Crib (8501) - Core Crib Assembly Steps

page 4
3a.) Slide the cross bar (P) into the
headboard side (A).
3b.) Attach the headboard side (A)
to side panels.
DO NOT OVERTIGHTEN.
P
A
P
A
H3
H3
Step 4a.)
Step 4b.)
Assemble the end panels (C & D), front legs (E & F) and rear legs (N & O).
DO NOT OVERTIGHTEN.
C D
E F
O N
STEP 2.
STEP 3.
H2H11
H2H11
H11H2
H11H2
H11H1
H11H1H1H11
H1H11
H11
H11
H11H2
H2H11
H2H11
H11H2
