Meade EXT90 - Key Features Identified on the Telescope


3
2
1
5
8
4
Figure 3: ETX90 Right Side
6
7
9





Q
S
1 Eyepiece
2 Red Dot Viewnder
3 Eyepiece Holder Thumbscrew
4 90° Eyepiece Holder
5 Optical Tube
6 Vertical Lock
7 Fork Arms
8 Focus Knob
9 Horizontal Lock
 Computer Control Panel
 ON/OFF Switch
 Auxiliary (AUX) Port
 Handbox (HBX) Port
 Battery Connector (not shown, accessible
thru battery compartment door on top of
base housing)
 LED
 Base Housing
1&
Battery Compartment (not shown, accessible
thru battery compartment door on top of
base housing)
1*
AutoStar Suite DVD
1(
Right Ascension (R.A.) Setting Circle

ETX90 KEY FEATURES
13
R
