PC-CARD-D24/CTR3 User's Guide Specifications
Table 7. Connector pin out
Pin Signal Name Pin Signal Name
1 Ext Int 26 A6
2 GND 27 A5
3 Int Enable 28 A4
4 GND 29 A3
5 CTR1 CLK 30 A2
6 GND 31 A1
7 CTR1 Gate 32 A0
8 GND 33 B7
9 CTR1 Out 34 B6
10 GND 35 B5
11 CTR2 CLK 36 B4
12 GND 37 B3
13 CTR2 Gate 38 B2
14 GND 39 B1
15 CTR2 Out 40 B0
16 GND 41 C7
17 CTR3 CLK 42 C6
18 GND 43 C5
19 CTR3 Gate 44 C4
20 GND 45 C3
21 CTR3 Out 46 C2
22 GND 47 C1
23 1 MHz Out 48 C0
24 GND 49 +5V
25 A7 50 GND
18
