PC-CARD-D24/CTR3 User's Guide Specifications
Crystal oscillator Frequency: 10 MHz
Frequency accuracy: 50 ppm
Miscellaneous: Available (divided by 10) at user connector (1 MHz Out)
Power consumption
Table 3. Power consumption specifications
+5V operating 45 mA typical, 65 mA max
Miscellaneous
Table 4. Miscellaneous specifications
Available at I/O connector (+5V Power)
+5 Volts DC
Protected by resettable fuse:
 Hold current: 350 mA
 Trip current: 700 mA
 Trip and recovery time: 100 m
S
Environmental
Table 5. Environmental specifications
Operating temperature range 0 to 70 °C
Storage temperature range -40 to 100 °C
Humidity 0 to 95% non-condensing
Connector and pin out
Table 6. Connector specifications
Connector type 50-pin connector
CPCC-50F-39: 50-pin Micro connector to 50-pin female IDC, one-meter cable
(39 inches).
Compatible cables
 CPCC-50M-4: 50-pin Micro connector to 50-pin male IDC, 4 inch adapter cable.
and
 C50FF-x: 50-
p
in IDC female to female cable. x = length in feet.
Compatible accessory products CIO-MINI50
CI-SPADE50
CIO-TERM100
SCB-50
SSR-RACK24
CIO-ERB24
CIO-SERB24
