PC-CARD-D24/CTR3 User's Guide Installing the PC-CARD-D24/CTR3
Field wiring and signal termination
You can use the following cabling, screw termination, and signal conditioning products with the CPCC-50F-39
cable, or with the CPCC-50M-4 and C50FF-x cables:
 CIO-MINI50 – 50-pin screw terminal board. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258
.
 C
IO-TERM100 – 100-pin screw terminal board (Two 50-pin IDC connectors). Details on this product
are
avai
lable on our web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=281
.
 C
IO-SPADE50 — 16" X 4" termination panel which mates with both 37-pin and 50-pin connect
ors.
Details on this product
are available on our web site at www.mccdaq.com/pdfs/specs/screw-spec.pdf.
 SC
B-50 – 50 conductor, shielded signal connection/screw terminal box provides two independent 50-pi
n
connect
ions. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168
.
 SSR
-RACK24 – 24-channel, solid-state relay mounting rack for digital signal conditioning. Details on this
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=1193
.
 CIO-ERB24 – 24 Form
C relays, 6 Amp relay accessory board for digital signa
l conditioning. Details on
t
his product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=241
.
 CIO-SERB24 – 24 Form
C relays, 10 Amp, fault detecting relay accessory board with socketed and field-
replaceable relays. Details on this produc
t are available on our web site at
www.m
ccdaq.com/cbicatalog/cbiproduct.asp?dept_id=123&pf_id=678
.
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to
Signal Connections (available at www.mccdaq.com/pdfs/DAQ-Signal-Connections.pdf).
Calibrating the PC-CARD-D24/CTR3
No calibration is required. There are no socketed or user-serviceable parts in the PC-CARD-D24/CTR3. The
case cannot be opened. Opening the case will void your warranty. If your PC-CARD-D24/CTR3 requires
service, contact the factory for an RMA# and return it
14
