Page 72 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 43132 Right Door 1
2 43050 Latch 1
3 53479 Screw PHMS M05-0.80 × 20 4
4 53043 WSHR M05 Spring Washer 4
5 53038 WSHR M05 Standard Flat Washer 4
6 REF Engine Tray Assembly (Refer to page 73) 1
7 50048 Nut NNYL M08 × 1.25 10
8 43133 Gas Shock Bracket 1
9 50031 Screw HHCS M08-1.25 × 25 6
10 43057 Gas Shock 2
11 43134 Gas Shock Bracket 1
12 50001 WSHR M08 Standard Flat Washer 12
13 53231 Screw PHMS M06-1.00 × 16 34
14 50047 Nut NNYL M06-1.00 34
15 50000 WSHR M06 Standard Flat Washer 34
16 43135 Hinge 1
REF - Reference
To Next Page
