Page: 11/16
3. If the vessel that holds water can not hold all water in the unit, before the
vessel that holds water is full of water, block the water outlet with the water
plug as soon as possible to prevent the water from flowing onto the ground or
carpet.
4). Once the water is fully drained, insert the water plug and screw on the water cap tightly.
Note: 1. Turn on the unit only after the water plug and drain cap are installed properly;
otherwise, the condensate of the unit will flow onto the ground or carpet.
Figure 10
2.
Continuous drain:
1). Screw off the water cap in the direction shown by the arrow and unplug the water plug;
(Figure 11)
2). Insert the OD 13mm PVC drain hose 8mm-10mm into the water outlet; (Figure 12)
3). Connect the drain hose to the WC or outdoor.
Note: 1. The drain hose must be installed when there is not water in the baseplate;
2. When operating in the cooling mode, to ensure the water for radiation of the
condenser of the
unit and enhance the cooling effects of the unit, it is
recommended that continuous drain not be set as far as possible when this
unit is in use;
3. When operating in the heating mode, adopt continuous drain; otherwise, the
unit may shut down due to full water;
4. Put the drain hose in an inaccessible place at a height not above the water
outlet and keep the drain hose free from flexure;
5. When continuous drain is adopted, keep the drain cap and water plug
properly.
Figure 11 Figure 12
Maintenance and Servicing
Drain
cap
Water plug
Water outlet
Drain hose
Drain cap
Water
plug
Water outlet
