Mec Micro 13-XD - Page 41

Page 37 Micro 13-XD - Service & Parts Manual
July 2020Section 13 - Chassis
Item Part Number Description Qty.
1 41223 Steer Cylinder Assembly (Without Seal Kit) 1
-- 41594 Seal Kit 1
2 41298 Straight Fitting 2
3 41318 Cover 2
4 41794 Screw 2
5 41322 Cotter Pin 4
6 41321 Pin 2
7 41225 Bearing 4
8 43564 Washer 2
9 41210 Bearing 4
10 44043 Steer Yoke Weldment 1
11 41228 Wheel 2
12 50003 WSHR M12 Standard Flat 2
13 53363 Castle Nut M12-1.75, Hex Thin Slotted 2
14 41323 Cover 2
15 53348 THMS M04-0.70 × 10 6
16 41230 Bearing Cover 2
17 53269 CSCS M05-0.80 × 16 8
18 41322 Cotter Pin 2
19 44029 Key 2
20 41233 Wheel Shaft 2
21 41024 Bearing 4
22 41234 Connection Plate 2
23 50429 HHCS M10-1.50 × 25 Serrated Flange 12
24 41327 Washer 2
25 53347 Castle Nut M16 × 1.50 2
26 41328 Cap 2
27 53282 CSCS M08-1.25 × 20 12
28 44042 Steer Yoke Weldment 1
29 41222 Bearing 2
30 41221 Tie Rod 1
31 50311 NNYL M10-1.50 Flange 2
32 41199 Washer 2
33 41202
Bearing 4
