Page 41 Micro 13-XD - Service & Parts Manual
July 2020Section 13 - Chassis
Item Part Number Description Qty.
1 41207 Pothole Guard Weldment 1
2 50430 HHCS M10-1.50 × 45 4
3 41211 Pin 2
4 41208 Pothole Guard Weldment 1
5 41210 Bearing 4
6 41209 Pin 4
7 50311 NNYL M10-1.50 Flange 8
8 41213 Pothole Link Plate 2
9 41214 Bearing 8
10 53349 NNYL M14-2.00 Flange 6
11 41212 Gas Shock Strut 2
12 41215 Gas Shock 2
13 53283 Set Screw M05-0.80 × 10 Cone Point 2
14 41319 Linkage Weldment 1
15 41216 Pin 2
16 41217 Roller 2
17 41320 Linkage Weldment 1
18 41220 Pothole Guide 1
19 41203 Bearing 4
20 41204 Pothole Hole Pusher Pin 2
21 44007 Adjusting Washer 2 2
22 44008 Adjusting Washer 3 2
23 41205 Pothole Hole Pusher Rod 2
