Page 43 Micro 13-XD - Service & Parts Manual
July 2020Section 13 - Chassis
Item Part Number Description Qty.
1 42891 Hydraulic Power Unit (Refer To Page 44) 1
2 41413 Nut 1
3 41297 Straight Fitting 1
4 43639 Elbow 3
5 41296 Straight Fitting 2
6 44053 Protect Cover 1
7 53350 Wing Nut M06-1.00 4
8 41330 Battery 2
9 44039 Towline 1
10 53352 CSCS M06-1.00 × 10 4
11 44040 Towline Bracket 1
12 53273 HHCS M06-1.00 × 14 Serrated Flange 2
13 REF Motor Controller Assembly (Refer To Page 46) 1
14 53038 WSHR M05 Standard Flat 8
15 53043 WSHR M05 Spring Washer 8
16 50359 SHCS M05-0.80 × 16 4
17 41075 Horn 1
18 53351 PHMS M05-0.80 × 16 8
19 53281 NNYL M05-0.80 Flange 8
20 43977 Latch 2
21 53264 PHMS M06-1.00 × 20 4
22 53353 PHMS M06-1.00 × 25 4
23 50568 NNYL M06-1.00 Flange 8
24 REF Ground Control Assembly (Refer To Page 48) 1
25 53348 THMS M04-0.70 × 10 8
26 41575 Plug 1
27 53263 THMS M04-0.70 × 8 2
28 44051 Battery Tray Weldment 1
29 53222 PHMS M05-0.80 × 8 4
30 42904 Charger 1
31 41255 Glide Track 2
32 53225 CSCS M10-1.50 × 30 2
33 41337 Bracket 1
34 50002
WSHR M10 Standard Flat 2
35 53054 WSHR M10 Spring Washer 2
36 50127 SHCS M10-1.50 × 30 2
REF - Reference
