Page 49 Micro 13-XD - Service & Parts Manual
July 2020Section 13 - Chassis
Item Part Number Description Qty.
1 53171 SHCS M05-0.80 × 30 2
2 43904 Decal, Ground Control Panel 1
3 44052 Ground Control Panel Weldment 1
4 41070 Hour Meter 1
5 41889 Controller 1
6 50284 WSHR M04 Standard Flat 4
7 50285 NNYL M04 × 0.70 4
8 41334 Relay 1
9 44054 Sleeve Pipe 2
10 42071 Emergency Switch 1
11 41419 Toggle Switch 1
12 41418 Key Switch 1
13 41421 Indicator 1
14 43991 Brake Release Switch 1
15 41422 Emergency Stop Switch 1
-- 43098 Red Mushroom Head 1
-- 43097 Base With 1 NC Contact 1
16 43992 Select Switch 1
-- 43993 Select Switch Head 1
-- 43994 Base With 1 NO Contact 1
-- 43096 NC Contact 1
To Next Page
