Page 51 Micro 13-XD - Service & Parts Manual
July 2020Section 13 - Chassis
Item Part Number Description Qty.
1 44041 Frame Weldment 1
2 53265 THMS M05-0.80 × 10 9
3 41308 Cover 1
4 41311 Cover 1
5 41257 Bearing 2
6 41312 Sensor Cover 1
7 53223 THMS M05-0.80 × 16 2
8 41193 Ladder 1
9 50031 HHCS M08-1.25 × 25 4
10 53055 WSHR M08 Spring Washer 4
11 50001 WSHR M08 Standard Flat 4
12 41194 Sensor Bracket 1
13 41195 Rotary Sensor 1
14 50284 WSHR M04 Standard Flat 6
15 53062 WSHR M04 Spring Washer 6
16 53065 SHCS M04-0.70 × 30 6
17 53356 SHCS M05-0.80 × 25 2
18 53038 WSHR M05 Standard Flat 8
19 41309 Beacon Cover 1
20 41310 Beacon 1
21 42406 Beacon Bracket 1
22 53281 NNYL M05-0.80 Flange 2
23 43978 Lock 2
24 53043 WSHR M05 Spring Washer 6
25 53173 SHCS M05-0.80 × 10 6
26 53113 SHCS M04-0.70 × 16 4
27 41197 Limit Switch 2
28 41315 Switch Cover 1
29 50423 SHCS M04-0.70 × 12 4
30 41198 Switch Cover 1
31 50289 HHCS M06-1.00 × 40 2
32 42403 Sensor Bracket 1
33 50568 NNYL M06-1.00 Flange 2
34 41098
Tilt Sensor 1
To Next Page
