Page 61 Micro 13-XD - Service & Parts Manual
July 2020Section 15 - Platform
Item Part Number Description Qty.
1 44038 Decal, Platform Control Panel 1
2 41149 Joystick 1
-- 43621 Function Enable Switch 1
-- 41150 Joystick Cover 1
-- 43622 Joystick Steer Switch 1
-- 43623 Switch Boot 1
3 41152 Coil Cord 1
-- 43624 Housing 1
-- 43625 Male Insert 1
-- 43626 Male Contacts 5
-- 43627 Cable Gland 1
4 43999 Platform Control Box Harness 1
-- 43628 Hood 1
-- 43629 Female Insert 1
-- 43630 Female Contacts 5
-- 43627 Cable Gland 1
5 41568 Alarm 1
-- 43631 Alarm Nut 1
6 41156 Main Board 1
-- 41155 Button 4
7 41157 Emergency Stop Switch 1
-- 43632 Red Mushroom Head 1
-- 43633 Base With 1 NC Contact 1
8 42915 Decal, Emergency Stop Panel 1
9 43634 Enclosure 1
10 43635 Cover Bottom 1
11 42596 Replacement Connector, Orange 1
-- 41271 Replacement Connector, Gray 1
