Page 67 Micro 13-XD - Service & Parts Manual
July 2020Section 16 - Hydraulic System
Item Part Number Description Qty.
1 41166 Fitting 1
2 43361 Washer 2
3 41167 Fitting 1
4 41290 Lift Cylinder 1
5 42480 Plug 1
6 41288 Pressure Sensor 1
7 44002 Washer 1
8 43638 Straight Fitting 1
9 44003 Solenoid Valve Spool 1
10 41747 Coil 1
11 53361 NHEX M06-1.00 1
12 50000 WSHR M06 Standard Flat 2
13 42466 Screw 1
14 41252 Emergency Down Cable Assembly 1
15 41162 Lowering Knob 1
16 41291 Plate 1
17 41292 Support 1
18 53179 HHCS M05-0.80 × 20 1
19 44004 Cable Connector 1
20 53362 NHEX 1/2-20 UNF 1
21 41295 Seal Kit 1
22 43369 Check Valve 1
23 42821 Plug 1
24 43370 Orifice 1
25 42553 Hose 1
26 41413 Nut 1
