Page 69 Micro 13-XD - Service & Parts Manual
July 2020Section 16 - Hydraulic System
Item Part Number Description Qty.
1 41296 Straight Fitting 2
2 41297 Straight Fitting 1
3 41298 Straight Fitting 2
4 43638 Straight Fitting 1
5 43639 Elbow 3
6 42480 Plug 1
7 42477 Hose Assembly 1
8 41366 Hose Assembly 1
9 44030 Hose Assembly 1
10 43361 Washer Seal 2
11 43104 Fitting, Banjo 1
12 42552 Bolt, Banjo 1
13 43103 Nut 2
14 42553 Hose 1
