Mec Micro 13-XD - Page 75

Page 71 Micro 13-XD - Service & Parts Manual
July 2020Section 17 - Electrical System
Item Part Number Description Qty.
1 42481 ECU Harness 1
2 44035 Limit Switch Harness, Pothole 1
3 44032 Pressure Sensor Harness 1
4 44037 Sensor Harness 1
5 44036 Lowering Valve Harness 1
6 42484 Drive Motor Harness 1
7 41921 Pump Motor Positive Harness 1
8 44055 Pump Motor Negative Harness 1
9 42489 Battery Negative Harness 1
10 41920 Battery Harness 1
11 44056 Battery Positive Harness 1
12 41918 Fuse Harness 1
13 44057 DC Contactor Harness 1
14 41917 Motor Controller Harness 1
15 REF Ground Control Assembly (Refer To Page 48) 1
16 REF Limit Switch, Pothole (Refer To Page 50) 2
17 REF Pressure Sensor (Refer To Page 66) 1
18 REF Rotary Sensor (Refer To Page 50) 1
19 REF Tilt Sensor (Refer To Page 50) 1
20 REF Beacon (Refer To Page 50) 1
21 REF Platform Control Box Assembly (Refer To Page 58) 1
22 REF Hydraulic Power Unit (Refer To Page 44) 1
23 REF Horn (Refer To Page 42) 1
24 REF Coil (Refer To Page 66) 1
25 REF Left Motor (Refer To Page 38) 1
26 REF Right Motor (Refer To Page 38) 1
27 REF Motor Controller (Refer To Page 46) 1
28 REF Motor (Refer To Page 44) 1
29 REF DC Contactor (Refer To Page 46) 1
30 REF 150A Fuse Assembly (Refer To Page 46) 1
31 REF Power Switch (Refer To Page 48) 1
32 REF Battery (Refer To Page 42) 2
33 REF Charger (Refer To Page 42) 1
34 41922
Harness, Platform Control Box 1
REF - Reference
