MECA EV01 - Base Plate

10 11
MECA EVO 1 Setup Guide | Pedal set assembly
MECA EVO 1 Setup Guide | Mechanical Adjustments
2) Mount baseplate to the rig
1x Plastic washer
1x Steel washer
1x M8X30 screw
1x Steel washer
1x M6 nut
Detail look
Mechanical adjustments
For baseplate adjustments, you will need 5mm and 4mm allen key and 10mm socket key
Bas e p lat e adjustments
30mm
55mm
Detail look
4mm allen key
