MECA EVO 1 Setup Guide | Mechanical Adjustments MECA EVO 1 Setup Guide | Mechanical Adjustments
For throttle pedal adjustments, you will need 5mm and 4mm allen key and 10mm socket
Throttle pedal adjustments
5mm allen key
3mm allen key
2,5mm allen key
Before adjusting, you
MUST remove pedal from
baseplate!
1x M4x10 screw
1x Steel washer
1x Plastic washer
1x M4 nut
1x Steel washer
1x M4x20
To change the faceplate, you have to loosen the spring preload on spring assembly and remove the rod from it's housing
+- 1kgf
Fine tuning
Ater every mechanical adjustment, we
recommend to perform recalibration
of the pedals.
4mm allen key
Before adjusting angle of
the pedal, unscrew only
ONE side at the time!
