MechMaxx SGR1500 - To-Scale Hardware

TO-SCALE HARDWARE
TO-SCALE HARDWARE
10
www. mechmaxx.com
Hardware graphics are printed at 1:1 scale for ease of identification. Simply place the hardware over the image in the
tables to verify it is the correct size.
M8 X 20mm
Hex bolt
6X
M8 X 25mm
Hex bolt
5X
M6 X 40mm
Hex bolt
2X
M12 X 55mm
Hex bolt
4X
8
Flat washer
6X
12
Flat washer
8X
14
Flat washer
2X
2X
nut M6
Hex lock
11X
nut M8
Hex lock
4X
nut M12
Hex lock
2X
nut M14
Hex lock
M16 X 360mm
Hex bolt
1X
